2. Commissioning
2-32
Festo P.BE-FB14-EN en 1411d English
Mo
dule
no.
Module Input address Output address
0 Bus nodes
CPX-FB14
Without activation of diagnostic functions
– –
1 Digital 8-off input module
CPX-8DE
T-PDO 1: I0 … I7
Obj. 6000.1
–
2 Digital 8-off input module
CPX-8DE
T-PDO 1: I8 … I15
Obj. 6000.2
–
3 Digital 4-off output module
CPX-4DA
– R-PDO 1: O0 … O3
Obj. 6200.1
4 Digital multi I/O module
CPX-8DE-8DA
T-PDO 1: I16 … I23
Obj. 6000.3
R-PDO 1: O4 … O11
Obj. 6200.1
Obj. 6200.2
5 Analogue 2-off input module
CPX-2AE-U-I
T-PDO 2: AI0 … AI1
Obj. 6401.1
Obj. 6401.2
–
6 Analogue 2-off output module
CPX-2AA
– R-PDO 2: AO0 … AO1
Obj. 6411.1
Obj. 6411.2
7 VTSA pneumatic interface
ISO plug-in (type 44)
DIL switch in the interface set to 1 ... 8
solenoid coils (8DO)
–
R-PDO 1: O12 … O19
Obj. 6200.2
Obj. 6200.3
Tab. 2/36: Configuration for example terminal 2 in Fig. 2/4
