1. Installation
1−18
Festo P.BE−CPX−FB38−EN en 0804NH
1.4 You will then comply with protection class IP65/IP67
In order to comply with protection class IP65/IP67, seal
unused sockets with the appropriate plugs and covers.
Port
Port IP65/IP67 Cover IP65/IP67
1)
L/A1, L/A2 (M12) Plug from Festo,
type NECU−M−S−D12G4−C2−ET
Protective cap from Festo,
type ISK−M12
Service interface (M12) Connecting cable and plug of the
handheld control unit (CPX−MMI)
Protective cap from Festo,
type ISK−M12
2)
1)
if connection is not used
2)
included in scope of delivery
Tab.1/5: Connections and covers for protection class IP65/IP67
