2. Commissioning
2−38
Festo P.BE−CPX−FB38−EN en 0804NH
You can obtain the software for the TwinCAT Information
System" in the internet at:
 http://www.Beckhoff.de
Detailed information as well as example projects and master
projects can be retrieved using the following keywords:
 PLC", Project", Library", Sample", Configuration",
Template", Tutorial" etc.
For further support, please contact your Festo service, e.g.
bymail:
 service_international@festo.com
2.4.5 EtherCAT topology representation
Symbolic representation
of the EtherCAT topology
and the CPX terminal
The topology display represents the structure of the
EtherCAT network and the Devices" and Boxes",
e.g. the CPX bus node and the corresponding CPX terminal
(4 in Fig.2/8).
The subsequent explanation describes the calling of the
topology display using Beckhoff TwinCAT.
Please note
The topology display however is first available after
completion of the EtherCAT network configuration.
The network configuration is described in section 2.4.3.
