1. Installation
1−20
Festo P.BE−CPX−FB38−EN en 0804NH
System supply, additional
supply and valve supply
The CPX terminal is supplied with operating and load power
via the manifold base with system, additional and valve
supply.
Plugs
Pin assignment of manifold base with
System supply
type CPX−GE−EV−S...
type CPX−M−GE−EV−S...
Additional power
supply
type CPX−GE−EV−Z...
type CPX−M−GE−EV−Z...
Valve supply module
type CPX−GE−EV−V...
7/8"−5POL
1
2
3
4
5
1: 0 V
VAL
/ 0 V
OUT
2: 0 V
EL/SEN
3: Earth connection
(incoming)
4: 24 V
EL/SEN
5: 24 V
VAL
/ 24 V
OUT
1: 0 V
OUT
2: not connected
3: Earth connection
(incoming)
4: not connected
5: 24 V
OUT

D
C
B
A
7/8"−4POL
1)
A: 24 V
EL/SEN
B: 24 V
VAL
/ 24 V
OUT
C: Earth connection
D: 0 V
EL/SEN
/
0 V
VAL
/ 0 V
OUT
(incoming)
A: not connected
B: 24 V
OUT
C: Earth connection
D: 0 V
OUT
(incoming)
A: not connected
B: 24 V
VAL
C: Earth connection
D: 0 V
VAL
(incoming)
2
3
4
1
M18
1: 24 V
EL/SEN
2: 24 V
VAL
/ 24 V
OUT
3: 0 V
EL/SEN
/
0 V
VAL
/ 0 V
OUT
4: Earth connection
1: not connected
2: 24 V
OUT
3: 0 V
OUT
4: Earth connection
1: not connected
2: 24 V
VAL
3: 0 V
VAL
4: Earth connection
1)
Note the specifications on the plug
V
EL/SEN
: Operating voltage for electronics/sensors
V
OUT
: Load voltage for outputs
V
VAL
: Load voltage for valves
Tab.1/6: Pin assignment for system supply, additional supply and valve supply
