Behaviour of the outputs in the Fail safe mode
(parameterisation)
In the Fail safe mode, output channels can assume one of the
following states:
Digital outputs/valves
Analogue outputs
Maintaining the current
condition (freeze" signal)
Maintaining the current
condition (freeze" signal)
Resetting the output channel
(factory setting)
Resetting of the output channel
to the analogue value 0
(factorysetting)
Setting the output signal Setting the required analogue
value (output signal)
Tab.2/16: Possible states of the output channels in the
Failsafe mode
If necessary, parameterise the required state of individual or
all output channels (outputs or solenoid coils or valves).
The status is set with the channel−specific module parameters
Faul mode" and Fault state".
In doing so, make sure that you assign the suitable setting to
each output.
Further information: see CPX system manual P.BE−CPX−SYS−...
