2.2 Type codes (ascertaining the features of a cylinder)
The precise features of a cylinder with piston rod can be ascertained with the help of the rating plate on the cylinder.
The type designation is directly beneath the Festo logo and describes the cylinder’s features separated by a hyphen (-).
Example:
DNCB-32-100-PPV-A
532728 X803
pmax. 12 bar
1
4
2
3
1 Type designation
2 Serial number
3 Technical information
4 Part number
The type designation on this rating plate provides the following information:
DNCB Cylinder of the type DNCB
100 Piston diameter 100 mm
100 Stroke 100 mm
PPV Adjustable end-position cushioning
A Sensing option (magnetic piston)
Note
A list and description of all possible equipment features of the cylinder with piston rod can be found in the data sheet.
It is available on the Festo website (www.festo.com).
2.3 Retrottingthecylinderwithpistonrodwithotherfeatures
The cylinder with piston rod of the type DNCB-… is only available in the standard design. It can be retrotted with a num-
ber of other features (e.g. dust protection “R8”) by installing a piston rod seal from the appropriate wearing parts kits.
Warning
All other components of the original DNCB wearing parts kit should also always be used.
Thefollowingfeaturescanberetrottedinthisway:
Feature Description Wearing parts kit with piston rod seal
R8 Protected against dust DNC-…-R8
A3 Unlubricated operation CDN-…-A3
CT Free of copper/PTFE DNC-…-CT
Please note that the removal and installation of alternative wearing parts kits are not described in these repair instruc-
tions. For information on how to do this, please refer to the repair instructions for cylinders with piston rod of the type
DNC-…. The relevant instructions, as well as a list of all compatible wearing parts kits, can be found on the Festo website
(www.festo.com).
