FIBARO ROLLER SHUTTER 3 User Manual

27
ADVANCED PARAMETERS
NOTE
Parameter 40 values
may be combined,
e.g. 1+2=3 means that
scenes for single and
double click are sent.
i
34. Alarm conguration - 5th slot (Heat)
This parameter determines to which alarm frames and how the device
should react. The parameters consist of 4 bytes, three most signicant
bytes are set according to the ocial Z-Wave protocol specication.
Available settings: 1B [MSB] - Notication Type
2B - Notication Status
3B - Event/State Parameters
4B [LSB] - action:
0 - no action
1 - open blinds
2 - close blinds
Default setting: [0x04, 0xFF, 0x00, 0x00]
(Heat Alarm, any notication, no action)
Parameter size: 4 [bytes]
NOTE
Parameter 41 values
may be combined,
e.g. 1+2=3 means that
scenes for single and
double click are sent.
i
40. S1 switch - scenes sent
This parameter determines which actions result in sending scene IDs
assigned to them.
Available settings: 1 - Key pressed 1 time
2 - Key pressed 2 times
4 - Key pressed 3 times
8 - Key hold down and key released
Default setting: 0 Parameter size: 1 [byte]
41. S2 switch - scenes sent
This parameter determines which actions result in sending scene IDs
assigned to them.
Available settings: 1 - Key pressed 1 time
2 - Key pressed 2 times
4 - Key pressed 3 times
8 - Key hold down and key released
Default setting: 0 Parameter size: 1 [byte]
SCENE TIGGERING CONFIGURATION
NOTE
Enabling triple click
for S1 in parameter 40
disables the ability to
add/remove via S1.
i

FIBARO ROLLER SHUTTER 3 Specifications

General

Device Type	Roller Shutter Controller
Protocol	Z-Wave
Radio Protocol	Z-Wave
Dimensions	42.5 x 38.25 x 20.3 mm
Mounting Box Requirements	Ø ≥ 50mm, depth ≥ 60mm
Protection Class	IP20
Maximum Load for AC Output	4.2A
Max Transmit Power	up to 6 dBm
Range	Up to 50m (open space)
Operating Temperature	0°C to 40°C
Z-Wave Frequency	868.4 MHz EU
Compatibility	Works with various Z-Wave and Z-Wave Plus certified devices
Radio Frequency	868.4 or 908.4 or 921.4 MHz EU frequency band
