2 Overview
Copyright © Fibocom Wireless Inc. 8
2 Overview
2.1 Introduction
FM101 is a highly integrated 4G WWAN module which uses M.2 form factor interface. It
supports LTE FDD/LTE TDD/WCDMA systems and can be applied to most cellular networks
of mobile carrier in the world.
2.2 Specification
2.2.1 RF Characteristic
FM101 RF characteristic is shown in Table 1:
Table 1. RF characteristic
Operating Band
FDD-LTE
B1/2/3/4/5/7/8/12/13/14/17/18/19/20/25/26/28/29/30/66/71
TDD-LTE
B38/39/40
1)
/41/42
1)
/43
1)
/48
2)
UMTS/HSPA+
B1/2/4/5/6/8/19
GNSS
GPS/GLONASS/Galileo/BDS
Data Throughput
LTE Peak
DL 300Mbps (CAT12)/UL 50Mbps (CAT4)
UMTS/HSPA+
Peak
DL UMTS: 384 kbps/UL 384 kbps
DL DC-HSPA+: 42 Mbps (CAT24)/UL 5.76 Mbps (CAT6)
Modulation Characteristic
LTE Modulation
3GPP Release 12
