Fibocom FM101-GL - 4.2 Operating Band

4 Radio Frequency
Copyright © Fibocom Wireless Inc. 48
Figure 22. Pulling JIG
Figure 23. Lift up pulling JIG
Figure 24. Pulling direction
4.2 Operating Band
The operating bands of FM101 module are shown in the following table:
Operating Band
Description
Mode
Tx (MHz)
Rx (MHz)
Band 1
2100MHz
LTE FDD/WCDMA
1920-1980
2110-2170
Band 2
1900MHz
LTE FDD/WCDMA
1850-1910
1930-1990
