3 Application Interface
Copyright © Fibocom Wireless Inc. 44
Pin
Pin Name
I/O
Reset Value
Pin Description
Type
USB 3.0 interface type
The M.2 module configuration is shown in the following table:
Config_0
(pin21)
Config_1
(pin69)
Config_2
(pin75)
Config_3
(pin1)
Module Type and Main
Host Interface
Port
Configuration
NC
GND
GND
GND
WWAN–SSIC
0
Please refer to “PCI Express M.2 Specification Rev4.0” for more details.
