4 Radio Frequency
Copyright © Fibocom Wireless Inc. 58
FM101 Module Main Antenna Requirement
LTE band 26 (850): 80 MHz
LTE band 28 (700): 100 MHz
LTE band 29 (700): 12 MHz
LTE band 30 (2300): 55 MHz
LTE band 66 (1700): 490MHz
LTE band 71 (680): 35MHz
LTE band 38 (2600): 50 MHz
LTE Band 39 (1900): 40 MHz
LTE band 40 (2300): 100 MHz
LTE band 41 (2500): 194 MHz
LTE band 42 (3500): 200 MHz
LTE band 43 (3700):200MHz
LTE band 48 (3600):150MHz
Bandwidth (GNSS)
GPS: 2 MHz
GLONASS: 8 MHz
BDS: 4 MHz
Galileo: 2 MHz
Impedance
50Ω
Input power
> 28 dBm average power WCDMA & LTE
Recommended standing-
wave ratio (SWR)
≤2:1
ANT on B30 suggestion: Peak gain < 1dBi, for FCC EIRP requirement,
Efficient > 50% for carrier TRP requirement. If integrator doesn't follow the
