3.5 USIM Interface
L610 modules provide USIM interface and support 1.8V and 3.0V SIM.
3.5.1 USIM Pin
USIM pins are shown in the following table:
Pin Name
I/O
Pin
Description
USIM_DATA
I/O
15
USIM/SIM DATA
USIM_CLK
O
16
USIM/SIM Clock Signal
USIM_RESET
O
17
USIM/SIM RESET Signal
USIM_VDD
O
14
USIM/SIM Power
USIM_PRESENCE
I
13
Detect USIM/SIM card for Hot-swap
3.5.2 USIM Interface Circuit
3.5.2.1 SIM Card Slot with Detection Signal
USIM/SIM design requires the use of SIM card slot (recommended model: SIM016-8P-220P). It is
recommended to use hot plug slot with SIM detection function.
