Pin
Pin Name
I/O
Level
Reset
Value
Description
143
RFCTL_1
I/O
VILmin=-0.3V
VILmax=0.6V
VIHmin=1.2V
VIHmax=2.0V
-
RFCTL_1
Left floating when not in use
144
RFCTL_2
I/O
VILmin=-0.3V
VILmax=0.6V
VIHmin=1.2V
VIHmax=2.0V
-
RFCTL_2
Left floating when not in use
Note:
 Unused pins remain floating. All GND pins are connected to the ground network.
 A single keyout/OUT button can not be used and needs to be used in conjunction with
KEYOUT/IN.
 When USB_BOOT/KEY_IN0 pin and KEYOUT are used as key function in combination, if the
corresponding key is pressed during power-on, the module will enter download mode because
KEYOUT has high pulse output during power-on.
 L610-CN-31/32 does not support KEYIN4/KEYIN5
3.1.3 Pin Multiplexing
For L610 pin multiplexing, please refer FIBOCOM L610 Series GPIO Function Multiplexing.
3.2 Power Supply
The power interfaces of L610 modules are shown in the following table:
Pin Name
I/O
Pin
Description
VBAT_RF
I
57,58
Module power supply, 3.4~4.3V, nominal value 3.8V
VBAT_BB
I
59,60
Module power supply, 3.4~4.3V, nominal value 3.8V
VDD_EXT
O
7
Voltage output, 1.8V
VDD_SDIO
PO
34
MMC powered LDO, default 3.1V
GND
G
8, 9, 19, 22, 36, 46,
48, 50-54, 56, 85-112
Ground
3.2.1 Power Supply
L610 modules need to be powered by the VBAT pin. The recommended power design is shown in Figure
3-2:
