L610 Module Main Antenna Requirements
Frequency range
It must use the most suitable antenna to adapt to the relevant frequency band
Bandwidth
(GSM/GPRS)
GSM850: 70 MHz
GSM900: 80 MHz
GSM1800(DCS): 170 MHz
GSM1900(PCS): 140 MHz
Bandwidth (LTE)
LTE band 1(2100): 250 MHz
LTE Band 2(1900): 140 MHz
LTE Band 3(1800): 170 MHz
LTE Band 4(2100): 145 MHz
LTE Band 5(850): 70 MHz
LTE Band 7(2500): 190 MHz
LTE Band 8(900): 80 MHz
LTE Band 20(800): 71 MHz
LTE Band 28(800): 100 MHz
LTE Band 66(2100): 470 MHz
LTE Band 34 (2100): 15 MHz
LTE Band 39(1900): 40 MHz
LTE band 40(2300): 100 MHz
LTE band 41(2500): 100 MHz
Impedance
50Ω
Input power
> 33dBm (2 W) peak power GSM
> 23dBm average power LTE
Standing wave ratio
recommended
≤ 2:1
