Fibocom L850-GL Series User Manual

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved.
FIBOCOM L850-GL Series Hardware Guide Page 17 of 59
Pin Pin Name I/O Reset Value Pin Description Type
23 WOWWAN# O PD
Wake up host,
Reserved
1.8V
24 I2S_TX O PD
I2S serial transmit data,
Reserved
1.8V
25 DPR I PU BodySAR detect, active low 3.3/1.8V
26 W_DISABLE2# I PU
GNSS disable, active low,
Reserved
3.3/1.8V
27 GND
- -
GND Power Supply
28 I2S_WA O PD
I2S word alignment/select,
Reserved
1.8V
29 USB3.0_TX- O
-
USB3.0 transmit data minus
-
30 UIM_RESET O L SIM reset signal 1.8V/3V
31 USB3.0_TX+ O
-
USB3.0 transmit data plus
-
32 UIM_CLK O L SIM clock signal 1.8V/3V
33 GND
- -
GND Power Supply
34 UIM_DATA I/O L SIM data input/output 1.8V/3V
35 USB3.0_RX- I
-
USB3.0 receive data minus
-
36 UIM_PWR O
-
SIM power supply, 3V/1.8V 1.8V/3V
37 USB3.0_RX+ I
-
USB3.0 receive data plus
-
38 NC
- -
NC
-
39 GND
- -
GND Power Supply
40 GNSS_SCL I PU
I2C serial clock input,
Reserved
1.8V
41 PETn0 O
-
PCIe TX differential signal
Negative
-
42 GNSS_SDA I/O PU
I2C serial data input/output,
Reserved
1.8V
43 PETp0 O
-
PCIe TX differential signal
Positive
-
44 GNSS_IRQ O PD
GNSS interrupt request output,
Reserved
1.8V
45 GND
- -
GND Power Supply

Fibocom L850-GL Series Specifications

General

Category	GSM/GPRS Modules
Model	L850-GL
Form Factor	M.2
Operating Temperature	-10°C to +55°C
Storage Temperature	-40°C to +85°C
GSM Bands	850/900/1800/1900MHz
GNSS	GPS, GLONASS, BeiDou, Galileo
Interface	USB 2.0, UART, PCM, I2C, GPIO
Operating Voltage	3.135V to 4.4V
LTE FDD	B1, B2, B3, B4, B5, B7, B8, B12, B13, B17, B18, B19, B20, B25, B26, B28, B29, B30, B66
LTE TDD	B38/B39/B40/B41
WCDMA	B1, B2, B4, B5, B8
AT Command Set	3GPP TS 27.007
Certifications	CE, FCC, GCF, PTCRB
