Fire-Lite CMP-2401B User Manual

The Main Power Supply
30
Document #50907 Rev.A1 12/03/02 P/N 50907:A1
1.
The current shown represents the CMP-2401B control panel in alarm. If both zones of the CMP-2402B con-
trol panel are in alarm, the current draw increases to 0.175 amps.
2.
Current limitations of terminals:
TB1, Terminals Ground and +24V Resettable = 0.085 amps, filtered, 24 VDC +/-5%, ripple @ 10mV
RMS
.
3.
Must use compatible listed Power Supervision Relay
4.
Enter current draw of each device. Current limitation of TB2 Notification Appliance Circuit is 1.25 amps.
TABLE 5-3:
Load in Alarm
Device Type # of Devices
Current
(amps)
Total Current
(amps)
Main Circuit Board 1 X
0.125
1
=
4XTMF (1 max.) X 0.045 =
Remote Trouble Unit (1 max.) X 0.050 =
4-wire Detector Heads
2
[ ] X [ ] =
Power Supervision Relays
3
[ ] X [ ] =
Notification Appliances
4
[ ] X [ ] =
Additional Current Draw
from TB1 (nonalarm)
2
=
Sum Column for Alarm Load = amps
