EQUIPMENT: FIRECLASS DUO -CEL WRITTEN BY: RKP
PUBLICATION: OM_FC_DUO-CEL_INST CHECKED BY: AP
ISSUE No. & DATE: 0 01/03/12
PAGE 21 of 29
and then are silent. Deactivate the Class
Change switch or timer.
5. Activate the Alert switch. Check that all
sounders pulse and the ALERT/EVAC ON LED
on the panel illuminates. Deactivate the Alert
switch. Check that the sounders are silent and
the panel indication clears.
6. Activate the Evacuate switch. Check that all
sounders operate and the ALERT/EVAC ON
LED on the panel illuminates. Deactivate the
Evacuate switch. Check that the sounders are
silent and the panel indication clears.
7. Press the EVACUATE button on the panel and
check that all sounders operate. Activate the
Remote Silence Alarms switch and check that all
sounders silence. Deactivate the Remote
Silence Alarms switch.
8. Activate a detector on any zone and check that
the panel indicates the alarm. Activate the
Remote Reset switch and check that the panel
clears the alarm indication. Deactivate the
Remote Reset Switch.
Any faults should be traced and rectified before
proceeding.
7.4 Fire Signal Output
1. Remove the 10K resistor from the Fire Signal
Output circuit terminals and connect the field
wiring to the terminals, observing correct
polarity. Check that any fault indications clear
after a few seconds (the relay at routing
equipment should have been connected as
shown in Figure 1).
2. To operate the output, initiate a fire condition on
a zone. Check that the panel illuminates the Fire
Signal On LED and that the fire signal is
received at the receiving station. Silence and
reset the fire alarm panel to clear the output.
3. Place a short circuit across the cables at the
routing equipment and check that the panel
indicates a Fire Signal Fault.
4. Remove the S/C and check that the fault
indication clears.
7.5 Ancillary outputs
1. Connect the field cabling into the Remote Output
terminals (DIS., EVAC., BUZ.).
2. The correct operation of equipment connected to
the Disablement Active output should be verified
by disabling/enabling a zone (see the User
Manual for details).
3. The correct operation of equipment connected to
the Evacuate Active output should be verified by
pressing the EVACUATE button on the panel.
4. The correct operation of equipment connected to
the Buzzer Active output should be verified by
disconnecting one battery lead to create a PSU
Fault indication (may take up to 60 seconds), the
internal buzzer & BUZ. Output will pulse.
Reconnect the battery lead after the test.
7.6 Repeaters
Repeaters can be connected once all other circuits
have been commissioned. Repeaters should be
connected one at a time to make fault-finding
easier. Ensure the repeaters have been correctly
configured as described in section 4.2.3.
1. At the first repeater, only connect the wiring
from the panel into the terminals on the
repeater as shown in Figure 11. DO NOT
connect the wiring for the 2
nd
& 3
rd
repeater.
2. At the panel, connect the repeater wiring into
the terminals as shown in Figure 11.
3. If the repeater is being powered from the
panel, then the repeater will power up as soon
as the power cables are connected into the
terminals at the panel.
The repeater will indicate a
COMMUNICATION FAULT and sound the
buzzer.
4. If the repeater has a separate power supply
then connect the red battery lead to the
batteries and energise the mains power to the
repeater.
The repeater will indicate a
COMMUNICATION FAULT and sound the
buzzer.
5. Configure the panel to communicate with one
repeater as detailed in section 6.2.
After a few seconds, the Communication Fault
at the repeater should clear and both the panel
& repeater should be in the quiescent state.
If the panel or repeater shows a fault then
trace and clear the fault before proceeding.
6. At the second repeater, only connect the wiring
from the first repeater into the terminals on the
repeater. DO NOT connect the wiring for the
3
rd
repeater.
7. At the first repeater, connect the second
repeater wiring into the terminals.
8. If the repeater is being powered from the
panel, then the repeater will power up as soon
as the power cables are connected into the
terminals at the first repeater.
The second repeater will indicate a
COMMUNICATION FAULT and sound the
buzzer.
9. If the repeater has a separate power supply
then connect the red battery lead to the
batteries and energise the mains power to the
repeater.
The second repeater will indicate a
COMMUNICATION FAULT and sound the
buzzer.
