See Figure 24, 2A.
If you stop the AUTO option at the end of the second
phase, the following results occur:
 The auto assignment of the address to the not
addressed devices
 The control panel will take over all devices
 The programming devices to their default configuration.
 Automatic assignment of labels.
 Automatic assignment of zones based on a loop of
belonging.
 The output channels of the modules, sounders and
beacons will be set to active on the alarm of the
assigned zone. See Figure 24, B.
3 Device mapping
The third and last phase is activated on demand at the end
of the auto-addressing phase.
In this phase, the following options are possible:
 Locate the positioning in the system of all the
devices through their activation.
 In the case of output modules only, sounders or
beacons, the devices will be suitably activated by
the panel (see Figure 24, 3A).
 Carry out a preliminary test of the system.
 Program the most important parameters of each
located device.
 Automatically assign labels to all devices.
 Automatically assign the zones based on the
assigned addresses of the devices.
 Automatically configure the output channels of the
modules, sounders, and beacons to activate on the
alarm of the assigned zone.
Table 60: Messages and required actions during the enroll process in function of the loop and panel
configuration.
Note: (*) indicates that the message is displayed and relevant action is executed.
LOOP
PANEL
MESSAGE
Differences found!
Automatic zones assignment
Not addressed
devices found
Start auto-
addressing
1
All devices not addressed
DEFAULT
*
2
Some devices addressed
+
Some devices not addressed
DEFAULT
(Applicable only to already
addressed devices)
*
*
3
All devices addressed
DEFAULT
*
4
Fully addressed
Same configuration
CONFIGURED
5
Fully addressed
Different configuration
CONFIGURED
*
New configuration
(Applicable only to all already
addressed devices)
*
Add devices
(Applicable only to new
already addressed devices)
*
6
Same configuration
+
Not addressed devices
CONFIGURED
*
7
Different configuration (*)
+
Not addressed devices
CONFIGURED
*
New configuration
(Applicable only to all already
addressed devices)
*
*
Add devices
(Applicable only to the new
already addressed devices)
*
*
