MANUAL for the basic control panel | CCB2.0
32
Read: The following table shows the read function of each communication address:
Address
Description
Reading
2010
Status read On/Off
Off→0, On→1
2012
Read conductivity value
0-1999 µS/cm*
2014
Read temperature value ºC
Divide the result by 100.
Ej. 1815 →18,15ºC
Address
Description
Reading range
Factory setting
2030
Read Timer T01
30-1000s*
90s
2032
Read Timer T02
1-15 min *
5min
2034
Read Timer T03
1-60 min *
10min
2036
Read Timer T04
30-400min*
60min
2038
Read Timer T05
0-24h *
0min=never
2040
Read Timer T06
0-24h *
1h
2042
Read Timer T07
5-360s*
30s
2044
Read Timer T08
10-60min*
15min
*These values are shown in seconds
Address
Description
Reading
2116
Read equipment live J25
0→not live (yellow led [3]Off)
1→live (yellow led [3]On)
2118
Read general equipment failure J23
0→no equipment failure(red led [4] Off)
1→equipment failure(red led [4] On)
2120
Read general equipment operation
status J24
0→not working
1→in operation
2122
Read UV lamp operation status J10
0→Off (blue led [11] Off)
1→On (blue led [11] On)
2→Fault (blue led [11] flashing)
2124
Read filling solenoid valve status J13
0→Off (yellow led [12] Off)
1→On (yellow led [12] On)
2126
Read drainage motor valve power status
J14
0→No power (green led [13] Off)
1→Powered (green led [13] On)
2128
Read drain motor valve position J15
1→closed (green led [14] Off)
0→open (green led [14] On)
2130
Read Level position status
0→Low-minimum (Yellow led [15])
1→Operating level J17(Green led [15])
2→Maximum water level J16(red led [15])
3→Level fault (red led [15] flashing)
