MANUAL for the basic control panel | CCB2.0
37
Object
Description
Reading
GET STATUS J11
(Analog_Input:12) =2132
Read pump status J11
0→not operating (green led [16] Off)
1→Operating (green led [16] On)
2→Pump fault (red led [16] On)
GET STATUS BREAKER
(Analog_Input:13) =2134
Motor pump circuit breaker
status
0→Circuit breaker fault
1→Circuit breaker correct
GET STATUS J18
(Analog_Input:14) =2136
UV lamp operating status
sensor J18
0→No fault
1→Fault
GET ALARMS
(Analog_Input:15) = 2200
Alarm, shows the equipment alarm code
0 → NO ALARM
1 → CPU
2 → CLOCK
4 →PROBE
8 →LEVEL SENSORS
16 →CIRCUIT BREAK FAULT
32 →UV FAULT
64 →DRAIN
128 →FILLING
256 →MOTOR VALVE 1
512 →DIRTY WATER
1024 →AUXILIARY FAULT
2048→UV LAMP EXPIRED
F4096 →AUXILIARY MODBUS 4096 FAULT
