Object
Description
Reading
GET STATUS J25
(Analog_Input:4)=2116
Read equipment live J25
0→not live (yellow led [3]Off)
1→live (yellow led [3]On)
GET STATUS J23
(Analog_Input:5)= 2118
Read general equipment
failure J23
0→no equipment failure(red led [4]
Off)
1→equipment failure(red led [4] On)
GET STATUS J24
(Analog_Input:6)= 2120
Read general equipment
operation status J24
0→not working
1→in operation
GET STATUS J10
(Analog_Input:7)= 2122
Read UV lamp operation
status J10
0→Off (blue led [11] Off)
1→On (blue led [11] On)
2→Fault (blue led [11] flashing)
GET STATUS J13
(Analog_Input:8)= 2124
Read filling solenoid valve
status J13
0→Off (yellow led [12] Off)
1→On (yellow led [12] On)
GET STATUS J14
(Analog_Input:9) = 2126
Read drainage motor valve
power status J14
0→No power (green led [13] Off)
1→Powered (green led [13] On)
GET STATUS J15
(Analog_Input:10) =2128
Read drain motor valve
position J15
1→closed (green led [14] Off)
0→open (green led [14] On)
GET STATUS J16&J17
(Analog_Input:11) =2130
Read Level position status
0→Low-minimum (Yellow led [15])
1→Operating level J17(Green led
[15])
2→Maximum water level J16(red
led [15]) 3→Level fault (red led [15]
flashing)
