Fig. 9.5-2: Diameter of conduits
Panda PVM-NE 6000 ND 25 40 8 8
Panda PVM-NE 6000i/8000i 20 40 8 8
Panda PVM-NE 8000 NE 25 40 8 8
Panda PVM-NE 9000 ND 25 40 8 8
Panda PVM-NE 12000 NE 25 40 8 8
Panda PVM-NE 14000 NE 25 40 8 8
Panda PVM-NE 15000 NE / 15000i 25 40 8 8
Panda PVM-NE 18 NE 25 40 8 8
Panda PVM-NE 24 NE 25 40 8 8
Panda PVM-NE 30 NE 25 40 8 8
Panda PVM-NE 35 YA 30 50 8 8
Panda PVM-NE 47 YA 30 60 8 8
Panda PVM-NE 40 LN 30 60 8 8
Panda PVM-NE 60 MB 40 76 8 8
Panda PVM-NE 75 MB 40 76 8 8
Panda PVM-NE 100 MB 50 76 8 8
Panda PVM-NE 110 DZ 50 76 8 8
Panda PVMH 8000 NE 25 40 8 8
Panda PVMH 12000 NE 25 40 8 8
Panda PVMH 14000 NE 25 40 8 8
Generatortyp
Generator type
Kühlwasser
Cooling water
Abgas
Exhaust
Kraftstoff
Fuel
Zulauf
Feed
Rücklauf
Return
Panda PVK-U 4000i/5000i 20 40 8 8
Panda PVK-U 4,5 ND 20 40 8 8
Panda PVK-U 5000 LPE 20 40 8 8
Panda PVK-U 6000 ND 25 40 8 8
Panda PVK-U 6000i/8000i 20 40 8 8
Panda PVK-U 8000 NE 25 40 8 8
Panda PVK-U 9000 ND 25 40 8 8
Panda PVK-U 12000 NE 25 40 8 8
Panda PVK-U 14000 NE 25 40 8 8
Panda PVK-U 15000 NE / 15000i 25 40 8 8
Panda PVK-U 18 NE 25 40 8 8
Panda PVK-U 24 NE 25 40 8 8
Panda PVK-U 30 NE 25 40 8 8
Panda PVK-U 35 YA 30 50 8 8
Panda PVK-U 47 YA 30 60 8 8
Panda PVK-U 60 MB 40 76 8 8
Panda PVK-U 75 MB 40 76 8 8
Panda PVK-U 100 MB 50 76 8 8
Panda PVK-UK 4000i/5000i 20 40 8 8
Panda PVK-UK 4,5 ND 20 40 8 8
