Installation Instructions
Seite/Page 86 - Kaptitel/Chapter 5: Installation Instructions 10.6.16
5.21 Technical Data
Characteristics
closed current (electronics off) 0,5 mA
closed current (electronics on) 10 - 15 mA
Benchmark figure of the temperature control:
fan start-up 60 °C - 80 °C
max. number of revolution 65 °C - 100 °C
tolerance of the temperatures ± 5 %
Maximum ratings
maximum ambient temperature (for operation) 50 °C
Maximum ratings: Battery operation 12 V
nominal load operating voltage (continuity) 11 VDC - 14.4 VDC
load operating voltage (15min) - 16.0 VDC
maximum idle speed operating voltage (3 sec) 17 VDC
nominal load current (continuity) 40 A
maximum load current (3 sec) 44 A
nominal voltage fan 12 VDC
Maximum ratings: Battery operation 24 V
nominal load operating voltage (continuity) 18 VDC - 28.0 VDC
load operating voltage (15min) - 28.8 VDC
maximum load operating voltage (3 sec) 30 VDC
idle speed voltage (continuity) 34 VDC
maximum idle speed operating voltage (3 sec) 36 A
nominal load current (continuity) 20 A
maximum load current (3 sec) 22 A
nominal voltage fan 24 VDC
Maximum ratings: Transformer operation 12 V
sieving in the power supply 10000 µF 63 V (depending on the load current)
data for secondary winding after rectification/sieving
nominal load operating voltage (continuity) 11 VDC - 14.4 VDC
load operating voltage (15min) - 16.0 VDC
maximum load operating voltage (3 sec) 17 VDC
idle speed operating voltage (continuity) 28 VDC
maximum idle speed operating voltage (3 sec) 30 VDC
nominal load current (continuity) 40 A
maximum load current (3 sec) 44 A
nominal voltage fan 12 VDC
Maximum ratings: Transformer operation 24 V
sieving in the power supply 10000 µF 63 V (depending on the load current)
data for secondary winding after rectification/sieving
full load operating voltage (15min) 18 VDC - 28.0 VDC
load operating voltage (15min) - 28.8 VDC
maximum full load operating voltage (3 sec) 30.0 VDC
maximum partial load operating voltage 36.0 VDC
idle speed operating voltage (continuity) 39.0 VDC
maximum idle speed operating voltage (3 sec) 40.0 VDC
maximum input peak voltage 44.0 VDC *1)
maximum output peak voltage 44.0 VDC *1)
nominal load current (continuity) 24 A
