Installation Instructions
Seite/Page 72 - Kaptitel/Chapter 5: Installation Instructions 10.6.16
5.14 Generator AC System Installation
Warning!: Electrical VoltageBefore the electrical system is installed, READ the
SAFETY INSTRUCTIONS of this manual FIRST!
Be sure that all electrical installations (including all
safety systems) comply with all required regulations of
the regional authorities. This includes lightening
conductor, personal protection switch etc.
5.15 AC-Control box
An AC-Control box is necessary for the operation of Panda generators. According to the generator capacity the AC
Control box is variable dimensioned and equipped. It is supplied with a lockable cap.
This cap must necessarily be locked when the generator is running, as at all models during operation, 400 V is
present in the AC control box.
For the excitation of the generator all necessary capacitorsand the starting current limitation (not available at all
models) are stored in the AC Control box. The AC Control box must be connected to the generator with the electrical
lines (230 V and 400 V).
Danger to life - 400V ACOnly qualified personnel may carry out working at the
AC Control box.
