Installation Instructions
Seite/Page 80 - Kaptitel/Chapter 5: Installation Instructions 10.6.16
5.16.3.2 FP CAN-Bus for internal use
The FP CAN-Bus termial is for internal use only.
5.16.3.3 Boostrelay (optional)
The Boostrelay connect extra capacitors to the generator for a short time to compensate peak load.
5.16.3.4 Line Relay (optional)
The line relay protect the consumers against undervoltage and overvoltage. At standard following parameters are
set:
Warning : +/- 6% generator nominal voltage.
Relay off: +/- 10% generator naminal voltage.
5.16.3.5 Autostart (optional)
With the autostart the generator can be started by an external signal (f.e. SPS).
5.16.3.6 Emergency Stop (optional)
With the emergency stop the generator will be stopped as soon as possible. All DC out will be disconnected (Line
relay, fuel pump, optional dc out etc.).
If not used, the connection must be bridged.
5.16.3.7 Fuel pump
The fuel pump is controlled by the xControl ECU.
5.16.3.8 Optional DC-OUT
The optional DC out is pre configurated.
At PMS generators for the external electrical water pump.
At vehicle generator for the fan control.
5.16.3.9 FP CAN-Bus RJ45
Connection for the external components of the xControl (Controlpanel, Paralleling Device etc.). At the end a
termination resistor must be set in.
5.17 Radiator fan control / electronic fan control
To control the radiator fan, various controls/electronic controls can be chosen from the Fischer Panda delivery
program.
Note!:In the following the basic functions of the fan controls
are described. The original manual/ data sheet with
further informations of the fan control must be
respected.
