Panda xControl
10.6.16 Kapitel/Chapter 11: Panda xControl - Seite/Page 181
20 Current sensor No voltage on supply current
sensor
short circuit
defect
Yes
25 Battery voltage battery voltage to low yes yes
26 RPM failure RPM out of range Failure fuel supply
Fuel empty
n.a. yes
29 Power out relay Failure power out relay Short circuit n.a. n.a.
65 AC-Voltage Voltage to high yes yes
66 AC-Frequency Frequency to high yes yes
67 AC-Current Current to high yes n.a.
68 AC-Power Load to high yes n.a.
70 Servo power Power to high mechanical blocked. Power
consumption to
high, short circuit
yes yes
72 Temperature Cylinder
head
Temp. value to high yes yes
73 Temperature winding Temp. value to high yes yes
74 Temperature Exhaust Temp. value to high yes yes
75 Temperature
Electronic
Temp. value to high yes n.a.
77 Starter power Starter failure short circuit
Starter defect
yes n.a.
78 Glow circuit Glow circuit failure short circuit
defect
yes n.a.
80 Fuel supply Failure fuel supply short circuit
defect
yes n.a.
81 Stop solenoid - Hold Failure stop solenoid hold coil short circuit yes n.a.
82 Stop solenoid - Pull Failure stop solenoid pull coil short circuit yes n.a.
83 Optional DC out Failure optional DC out short circuit yes n.a.
89 Battery voltage Battery voltage to high yes yes
93 Power out relay Failure power out relay Short circuit or defect yes Yes
130 No Panel found Wrong patch cable/wrong
contact
check cable/harness n.a. yes n.a.
131 Communication FP
BUS
Communication failure lost communication with Panel n.a. yes
132 Service interval Service due yes n.a.
133 BUS Module lost (3ph-
measurement)
yes n.a.
134 BUS Module lost (DC-
measurement)
n.a. yes
135 Sync failure generators cannot be synced second generator can not be
switched to the running
generator
Yes
136 Communication
motorcontroller
No data from motorcontroller short circuit
defect
Yes
137 Airfilter Error Airfilter Bad airfilter Yes
139 Syncmodul No data from Syncmodul short circuit
defect
Yes
140 loadbancing Generator takes
less of load
Generator produces not
enough power
Yes
141 Configuration
syncmodul
Syncmodul available but not
selected
Crippled mode only No
246 Service done user Service interval reset n.a. n.a. yes
251 Admin Param changed user Parameter changed in Admin
level
n.a. n.a. yes
No.. Description Cause Explication Warning Gen.Stop Info
