Fisher Speed-Caster - Adjusting Gates and Deflector

Lit. No. 13648/9511, Rev. 07 9 August 10, 2005
OPERATING THE SPREADER
Adjusting the Gates and the Deflector
Spread pattern, pattern width, and the amount of
material dispensed are dependent on the spinner
speed, gate position, and deflector position.
Deflector Effect
Gate Effect
Driver side
open.
Passenger side
open.
Both sides
open.
Passenger side gate closed.
Heavy on passenger side.
Driver side gate closed.
Heavy on driver side.
Both Gates Open.
WARNING
Before making any adjustments to the gate/
deflector settings, turn the spreader off. Wait
for all conveyor or spinner movement to stop.
