Lit. No. 13648/9511, Rev. 07 5 August 10, 2005
MOUNTING THE SPREADER
In-Bed Mount
1. Remove the tailgate from the vehicle.
2. Place the mount assembly into the bed of the
vehicle.
3. Slide the assembly forward engaging the locator
studs.
4. Secure the front of the mount assembly to the
channel using hold-down bolts. Hand tighten.
NOTE: Apply a small amount of grease to the bolt
thread periodically to ensure easy removal.
Locator
Studs
Mount
Assembly
Tab
Hold-down
Bolt
5. Lift the hopper assembly using a hoist or two
people, and tip slightly forward.
6. Position the tabs of the hopper assembly over the
top of the mount assembly, and lower.
7. Allow the hopper assembly to lower into position.
