I n t r o d u c t i o n
1 5
Serial Port
■ The Back
󱈹
Parallel Port
Mouse Connector
Video Connector
Selector Switch
for Keyboard
Line in
M i c r o p h o n e
J o y s t i c k / M i d i
Wireless Keyboard
ID Reset Switch
Keyboard Connector
▶ Select between wired and
wireless keyboard
▶ Output terminal for
external speakers
▶ Game port and Midi
▶ Terminal for External
M i c r o p h o n e
▶ The reset switch for the
wireless keyboard ID
▶ External monitor
connection point
▶ PS/2 type mouse connector
▶ Communication port (COM1)
▶ Printer port (LPT1)
▶ PS/2 type keyboard connector
Speaker Out
USB Port
Power Connector
RJ-45 Port
▶ Input for 240V/100V
p o w e r
▶ 1 0 / 1 0 0 M b p s
Ethernet port
▶ Port for USB
c o n n e c t i o n
