FLATOP AF8 - Connector Functions

6 2
Improved Computer Performance
Cont 1 LCD interface cable connector (for LCD output)
Cont 2 FAN 1: CPU Cooling fan′spower connector (permitted changing with Cont 3)
Cont 3 FAN2: External radiator fan′spower connector (permitted changing with Cont 2)
Cont 4 Cooling fan′spower connector
Cont 5 Inverter Connector
Cont 6 IR connector
Cont 7 Internal Microphone connector
Cont 8 Serial Port 2 connector
Cont 9 External serial port, parallel port, VGA port connector
C o n t 11 USB, Ethernet port connector
C o n t 1 2 Sound, keyboard and mouse connector
C o n t 1 3 Line in connector
C o n t 1 4 Left speaker connector
C o n t 1 5 MiCom Test (Don′t used)
For correct connection, check the mainboard′sconnector information
Connector Functions
1. Make a record of the information on the connection status before you
remove the connectors.
2. Connect the hard disk drive, floppy disk drive and CD-ROM drive
connectors according to their directions.
!
