6600 – 6665 – 6700 – 6765
195
10 - POWER HEAD 6700 / 6765
TETE DE COMMANDE / STEUERKOPF / CABEZA DE MANDO /
PANNELLO DI COMMANDO / PROGRAMMEERKOP
ITEM QTY P/N DESCRIPTION
1 1 25329 Retrofit Kit Drive Motor Assy 24V/50Hz 2 RPM
2 1 17841-020 Cover 6700 Bottom Black
3 1 17845 Pin Hinge 6700
4 1 BU28597 Kit Transfo 10 VA 400 mA Resid
5 1 BU17842-00 Cover Top 6700 Smoke
1 BU17842-07 Cover Top 6700 Blue
6 1 15151 Screw Flat Head
7 1 18679 Tapered Cap 6700
8 2 BU11413 Screw
9
1 26220-10 Front Panel Assy Elec 6700 DF
1 26634 Front Panel Assy Elec 6700UF/6765
1 28026 Front Panel Assy Elec 6765 – 6 cycles
10
1 17438 Drive Cam DF Black
1 17885 Drive Cam UF Red
1 24601 Drive Cam UF 6 cycles Green
11 1 19121-01 Meter Cable
12 2 BR40422 Wire Nut Tan
13 1 13547 Strain Relief 24V
14 1 10302 Insulator Limit Switch
15 1 2226-C45 Chlorine Harness
16 1 18722 Brine Cam DF/UF
