Fleck 6600 User Manual

6600 – 6665 – 6700 – 6765
196
11 - VALVE BODY
CORPS DE VANNE / VENTILKORPER / CUERPO DE LA VALVULA /
CORPO DELLA VALVOLA / LICHAAM VAN DE KLEP
ITEM QTY P/N DESCRIPTION
1 3 12112 Screw
2 1 BU13546 Plug Retainer
3
1 27077 Piston assy 6600/6700 DF
1 26123 Piston assy 6665 6 cycles & 6765 6 cycles
1 25593 Piston assy 6600/6700 UF
4 1 24115 Seals & Spacers Kit
5 1 24509-01 Mixing assy for Residential
6
1 28405-20 Valve Body Residential DF Mixing
1 28405-40 Valve Body Residential UF Mixing
7 1 13304-01 O'ring
8 1 BU13030 O'ring Retainer for Residential Valve
9 1 12281-01 O'ring Top of Tank
10
1 VCINJ1 Injector assy
1 BU28829 Injector assy 1600 6665/6765 00/1.2/0.25
11 1 13497 Disperser air
12
1 BU28825-0.12 Kit Chlorine cell 6665/6675 w/BLFC 0.125
1 BU28825-0.25 Kit Chlorine cell 6665/6675 w/BLFC 0.250
1 BU28825-0.50 Kit Chlorine cell 6665/6675 w/BLFC 0.500
13
1 BU28824-0.12 BLFC Assy 6665/6765 0.125 GPM
1 BU28824-0.25 BLFC Assy 6665/6765 0.250 GPM
1 BU28824-0.50 BLFC Assy 6665/6765 0.500 GPM
Valve body assembly / Corps de vanne assemblé / Ventilkörper komplett / Cuerpo de la válvula ensamblado /
Corpo della valvola assemblato / Geassembleerd kleplichaam
P/N DESCRIPTION
BU28520-06 Valve Body Assy 6600/6700 DF
BU28520-07 Valve Body Assy 6600/6700 UF
BU28520-08 Valve Body Assy 6665/6765 6 cycles
