FF20 IH EN 74-215-051 v1.02.doc Version: 1.02 Page 11 of 21
3.5.3 Services
All electrical systems are placed underneath the base plate.
3.5.3.1 Power supply:
3.5.3.2 Compressed air supply:
Note:
Only authorised personnel can gain access to the installations.
The main power cable must be removed completely from power supply before the installations are
touched.
3.5.4 Bottles and trays
Bottle sizes
Diameter From Ø12 mm to Ø78 mm.
Tray size inlet / outlet
Inlet Outlet
Length / width 307 mm / 366 mm 307 mm / 366 mm
Height of rail 30 mm 30 mm
3.5.5 Ingress protection
Ingress protection IP32
3.5.6 Weight
Weight: app. 40 kg
3.5.7 Materials of construction
AISI304 stainless steel
Anodised aluminium
3.5.8 Optional fillers and capping machines
FF20 must be connected to a peristaltic filler in order to perform indexing of bottles.
Optional WMF fillers when filling are:
- PF6 or PF22 Peristaltic filler
- MC12 with PD12 or PD22 peristaltic filler
- 520 Di peristaltic filler
