Flintec FT-13 - 7.3.5 Programme 4: Filling and Discharging

FT-13 Technical Manual, Rev. 1.40 March 2013
Page 23 of 56
7.3.5 Programme 4: Filling and Discharging
FT-13
DISC HARG E
FT-13FT-13
Discharge
FT-13FT-13
DISC HARG E
FT-13FT-13
Discharge
Application:
Tank / silo / hopper filling / charging
Multi cycle discharging of tank / silo / hopper
Operation:
The start input starts the 2-speed or 3-speed
filling of the tank/hopper until the target value
The discharge input starts the 2-speed or 3-
speed discharging until the target value
Filling and discharging processes can be
choosen freely. For example, the tank can be
filled up to 3000 kg and 180kg can be
discharged sequentially.
Process Parameters
Description
+ + +
When type FT-13 is in the “Ready” status (the top LED in
the LED bar is “on” ) press the keys shown on the left
sequentially.
This is the period for displaying messages to be shown
after filling and discharging. It can be enterred by keypad up
to 25.0 s.
Zero range.
If the weight is in this range, it means the scale is empty. To
start the filling the weight has to be in the zero range.
Exit
Process Messages
Description
This message is shown at the end of the filling.
This message and the weight are shown alternately until
the container is removed from the platform.
This message is shown at the end of the discharging.
It is shown alternately to the weight value.
d_∩SG
X
dSchrG
XXXXX
FULL
XXXXX
XXXXX
ZEro_r
