FT-13 Technical Manual, Rev. 1.40 March 2013
Page 36 of 56
Start : Start time of the first filling / discharging cycle
End : End time of the last filling / discharging cycle
N : Number of filling / discharging cycles
NC : Number of controlled filling / discharging cycles
Control Conditions:
Preact correction is done (see parameter [502] in chapter 7.6)
The filling / discharging weight must be within the preact
correction limit. (see parameter [503] in chapter 7.6)
N<t : Number of filling / discharging cycles below tolerance
N>t : Number of filling / discharging cycles above tolerance
Nok : Number of filling / discharging cycles within tolerance
Avg : Average value of the filling / discharging weight value
S : Standard deviation. Only controlled filling / discharging
cycles are evaluated
Min : Minimum filling / discharging weight value
Max : Maximum filling / discharging weight value
R : Maximum weight value – Minimum weight value
Total : Total weight of filling / discharging
If the filling / discharging weight is controlled, the exact filling or
discharging weight is added to the “Total” value. If the filling /
discharging weight is not controlled, the target value is added to the
“Total” value.
8.2.6 Setup
[0--] Interface Block
You can access the parameters of the instruments‟s serial interface(s) in parameter section [0--]. The data output modes
(see chapter 8.3) can be used only once except for continuous data output.
[00-] Serial Interface 1 (Standard serial interface)
[000 X ] Data Format
0 : No data transfer
1 : Continuous data output
2 : Print mode
3 : Host mode
[001 X] Baud Rate
0 : 1 200 Baud
1 : 2 400 Baud
2 : 4 800 Baud
3 : 9 600 Baud
4 : 19 200 Baud
5 : 38 400 Baud
6 : 57 600 Baud
[002 X] Handshake
0 : No Handshake
1 : Xon/Xoff
[003 XX] Address
You can define a device address between 1 and 99 by this parameter. Entry 0  no address.
[004 X] Data Length and Parity
0 : 8 bit, no parity
1 : 7 bit, odd parity
2 : 7 bit, even parity
[005 X] Checksum
0 : Checksum byte disabled
1 : Checksum byte enabled
[02-] Serial Interface 2 (Optional serial interface)
[020 X ] Data Format
0 : No output
1 : Continuous data output
2 : Print mode
3 : Host mode
4 : Modbus RTU High-Low*
5 : Modbus RTU Low-High**
* Modbus RTU, high word before low word at address 40001 and 40002
** Modbus RTU, low word before high word at address 40001 and 40002
[021 X] Baud Rate
0 : 1 200 Baud
1 : 2 400 Baud
2 : 4 800 Baud
0 : 1 200 Baud
4 : 19 200 Baud
5 : 38 400 Baud
6 : 57 600 Baud
[022 X] Handshake
0 : No Handshake
1 : Xon/Xoff
BATCH REPORT
Start : dd.mm.yyyy hh:mm
End : dd.mm.yyyy hh:mm
N = xxxxxx
NC = xxxxxx
N<t = xxxxxx
N>t = xxxxxx
Nok = xxxxxx
Avg = xxxxxx kg
S = xxxxxx kg
Min = xxxxxx kg
Max = xxxxxx kg
R = xxxxxx kg
Total = xxxxxx kg
