FLIR E85 User Manual

Annotating images18
8. To listen to the recording, select
(Play) and push the navigation pad.
9. To delete the recording, select
(Delete) and push the navigation pad.
10. When completed, select
(Done) and push the navigation pad.
18.5 Adding a sketch
18.5.1 General
You can add a freehand drawing to an infrared image.
18.5.2 Procedure
Follow this procedure:
1. Open the image in the image archive.
2. Push the navigation pad to display the top toolbar.
3. On the top toolbar, select the
icon and push the navigation pad.
4. On the right toolbar, select the
icon and push the navigation pad.
5. You are now in sketch mode. Draw the sketch by touching the screen.
#T810190; r. AL/47698/47698; en-US
94
