FLIR E85 User Manual

Technical data27
27.10 FLIR E75 24° + 42°
P/N: 78505-0101
Rev.: 47553
Imaging and optical data
Infrared resolution 320 × 240 pixels
UltraMax (super-resolution) In FLIR Tools
NETD
• <30 mK, 42° @ +30°C (+86°F)
• <40 mK, 24° @ +30°C (+86°F)
• <50 mK, 14° @ +30°C (+86°F)
Field of view
• 42° × 32°
• 24° × 18°
• 14° × 10°
Minimum focus distance
• 0.15 m (0.49 ft.), 42°
• 0.15 m (0.49 ft.), 24°
• 1.0 m (3.28 ft.), 14°
Minimum focus distance with MSX
• 0.65 m (2.13 ft.), 42°
• 0.5 m (1.64 ft.), 24°
• 1.0 m (3.28 ft.), 14°
Focal length
• 10 mm (0.39 in.), 42°
• 17 mm (0.67 in.), 24°
• 29 mm (1.41 in.), 14°
Spatial resolution (IFOV)
• 2.41 mrad/pixel, 42°
• 1.31 mrad/pixel, 24°
• 0.75 mrad/pixel, 14°
Additional lenses
• 14°
Lens identification Automatic
f number
• 1.1, 42°
• 1.3, 24°
• 1.5, 14°
Image frequency 30 Hz
Focus
• Continuous LDM
• One-shot LDM
• One-shot contrast
• Manual
Field of view match Yes
Digital zoom 1–4× continuous
Detector data
Focal plane array/spectral range Uncooled microbolometer/7.5–14 µm
Detector pitch 17 µm
Image presentation
Resolution 640 × 480 pixels (VGA)
Surface brightness (cd/m
2
)
400
Screen size
4 in.
#T810190; r. AL/47698/47698; en-US
154

FLIR E85 Specifications

General

Thermal Sensitivity	< 0.04°C
Field of View	24° × 18°
Temperature Range	-20°C to 650°C
Image Frequency/Frame Rate	30 Hz
Image Frequency	30 Hz
Battery Life	up to 4 hours
Battery Operating Time	up to 4 hours
Accuracy	±2°C or ±2% of reading
Digital Zoom	1-4x continuous
Laser Pointer	Yes
Laser Distance Meter	Yes
Storage Media	SD Card
Operating Temperature Range	-15°C to 50°C
Storage Temperature Range	-40°C to 70°C
Connectivity	Wi-Fi, USB, Bluetooth
Thermal Sensitivity/NETD	< 0.04°C @ 30°C
Temperature Range (Low)	-20°C to 120°C
Weight	1.2 kg
Digital Camera	5 MP
Battery Type	Li-ion
Spectral Range	7.5 - 14 µm
Display	4-inch LCD touchscreen
