FLIR E85 - Camera Parts; View from the Front

Camera parts
8
8.1 View from the front
8.1.1 Figure
8.1.2 Explanation
1. Laser distance meter.
2
2. Infrared lens.
3. Focus ring.
4. Autofocus button.
2
5. Trigger.
6. Lamp for the digital camera (left and right sides).
7. Digital camera.
#T810190; r. AL/47698/47698; en-US
18
2. This item is dependent on the camera model.
