Technical data27
Video recording in camera
Radiometric infrared-video recording RTRR (.csq)
Non-radiometric infrared-video recording H.264 to memory card
Visual video recording H.264 to memory card
Video streaming
Radiometric infrared–video streaming
(compressed)
Yes: over UVC or RTSP (Wi-Fi)
Non-radiometric video streaming (compressed: IR,
MSX, visual, Picture in Picture)
• H.264 (AVC) over RTSP (Wi-Fi)
• MPEG4 over RTSP (Wi-Fi)
• MJPEG over UVC and RTSP (Wi-Fi)
Visual video streaming Yes
Digital camera
Resolution 5 MP with LED light
Focus Fixed
Field of view
53° × 41°
Video lamp Built-in LED light
Laser pointer
Laser alignment Position is automatically displayed on the infrared
Laser distance meter Activated by a dedicated button
Laser Class 2, 0.05–40 m (1.6–131 ft.) ±1% of measured
distance
Data communication interfaces
Interfaces USB 2.0, Bluetooth, Wi-Fi, DisplayPort
METERLiNK/Bluetooth Communication with headset and external sensors
Wi-Fi Peer to peer (ad hoc) or infrastructure (network)
Audio Microphone and speaker for voice annotation of
images
USB USB Type-C: data transfer/video/power
USB standard USB 2.0 High Speed
Video out DisplayPort
Video connector type DisplayPort over USB Type-C
Power system
Battery type Rechargeable Li-ion battery
Battery voltage 3.6 V
Battery operating time > 2.5 hours at 25°C (68°F) and typical use
Charging system In camera (AC adapter or 12 V from a vehicle) or
two-bay charger
Charging time (using two-bay charger)
2.5 hours to 90% capacity with charging status in-
dicated by LEDs
Charging temperature 0°C to +45°C (+32°F to +113°F), except for the Ko-
rean market: +10°C to +45°C (+50°F to +113°F)
#T810190; r. AL/47698/47698; en-US
260
