FLIR E85 User Manual

Working with measurement tools16
4. In the dialog box, you can define the settings for the alarm.
• Alarm condition: The condition that triggers the alarm. Applicable values are Above,
Below, or Off.
• Alarm limit: The temperature value that will be the critical condition when an alarm is
triggered or not.
• Alarm sound: Applicable values are Beep or No sound.
5. Push the navigation pad. This closes the dialog box.
16.8.4.2 Setting up an alarm for a box or circle
Note This procedure assumes that you have previously set the camera to display at least
one value (maximum, minimum, or average) in the result table. For more information, see
section 16.6 Displaying values in the result table, page 80.
Follow this procedure:
1. To select the measurement tool, touch the tool on the screen. The tool is now dis-
played with one or more handles.
2. Push the navigation pad—or touch and hold the tool. This displays a context menu.
3. Select
(Set alarm) and push the navigation pad. This displays a dialog box.
4. In the dialog box, you can define the settings for the alarm.
• Alarm condition: The condition that triggers the alarm. Applicable values are Above,
Below, or Off.
• Select measurement: Applicable settings are the values you have previously de-
fined (Max, Min, and/or Avg).
• Alarm limit: The temperature value that will be the critical condition when an alarm is
triggered or not.
• Alarm sound: Applicable values are Beep or No sound.
5. Push the navigation pad. This closes the dialog box.
#T810190; r. AL/47698/47698; en-US
83

FLIR E85 Specifications

General

Thermal Sensitivity	< 0.04°C
Field of View	24° × 18°
Temperature Range	-20°C to 650°C
Image Frequency/Frame Rate	30 Hz
Image Frequency	30 Hz
Battery Life	up to 4 hours
Battery Operating Time	up to 4 hours
Accuracy	±2°C or ±2% of reading
Digital Zoom	1-4x continuous
Laser Pointer	Yes
Laser Distance Meter	Yes
Storage Media	SD Card
Operating Temperature Range	-15°C to 50°C
Storage Temperature Range	-40°C to 70°C
Connectivity	Wi-Fi, USB, Bluetooth
Thermal Sensitivity/NETD	< 0.04°C @ 30°C
Temperature Range (Low)	-20°C to 120°C
Weight	1.2 kg
Digital Camera	5 MP
Battery Type	Li-ion
Spectral Range	7.5 - 14 µm
Display	4-inch LCD touchscreen
