Figure

10781003;a1

Explanation

This table explains the figure above:

Archive button

Function: Push to open the image archive.

Left arrow button (on the navigation pad)

Function:

■

Push to go left in menus, submenus, and dialog boxes

■

Push to navigate in the image archive

Left selection button. This button is context-sensitive, and the current

function is displayed above the button on the screen.

+ button (on the navigation pad)

Function:

■

Push to go up in menus, submenus, and dialog boxes.

■

Push to display the image archive (after having pushed the Archive

button).

■

Push to increase/change the value.

Publ. No. T559580 Rev. a486 – ENGLISH (EN) – November 17, 2010 11

8 – Camera parts
