FLIR i3 User Manual

Right arrow button (on the navigation pad)
Function:
■
Push to go right in menus, submenus, and dialog boxes.
■
Push to navigate in the image archive.
5
Right selection button. This button is context-sensitive, and the current
function is displayed above the button on the screen.
6
On/Off button
Function:
■
Push to turn on the camera.
■
Push and hold down for more than one second to turn off the camera.
7
– button (on navigation pad)
Function:
■
Push to go down in menus, submenus, and dialog boxes.
■
Push to decrease/change the value.
8
12 Publ. No. T559580 Rev. a486 – ENGLISH (EN) – November 17, 2010
8 – Camera parts

FLIR i3 Specifications

General

Infrared Resolution	60 x 60 pixels
Thermal Sensitivity	< 0.15°C
Temperature Range	-20°C to +250°C
Field of View	12.5° x 12.5°
Focus	Fixed
Battery Life	5 hours
Operating Temperature	-10°C to +50°C
Storage Temperature	-40°C to +70°C
Display	2.8 in color LCD
Weight	0.34 kg
