FLIR K 5 Series

Technical data14
Power system
Battery type Li Ion
Battery voltage 3.6 V
Battery capacity 4.4 Ah, at +20°C to +25°C (+68°F to +77°F)
Battery operating time Approx. 4 hours at +25°C (+77°F) ambient tem-
perature and typical use
Charging system
• Battery is charged inside the camera
• 2-bay charger
• Optional In-truck charger
Charging time
2 h to 85% capacity, charging status indicated by
LEDs
Charging temperature 0°C to +45°C (+32°F to +113°F)
Power management Automatic shutdown and sleep mode
Start-up time from sleep mode
< 4 s.
Start-up time < 17 s. (IR image, no GUI)
Environmental data
Operating temperature range
• –20°C to +85°C (–4°F to +185°F)
• +150°C (+302°F): 15 min.
• +260°C (+500°F): 5 min.
Storage temperature range –40°C to +85°C (–40°F to +185°F)
Humidity (operating and storage) IEC 60068-2-30/24 h 95% relative humidity +25°C
to +40°C (+77°F to +104°F) / 2 cycles
Relative humidity 95% relative humidity +25°C to +40°C (+77°F to
+104°F) non-condensing
Directives Designed to meet NFPA 1801:2013 specification:
• Vibration
• Impact acceleration resistance
• Corrosion
• Viewing surface abrasion
• Heat resistance
• Heat and flame
• Product label durability
EMC
• EN 61000-6-2:2005 (Immunity)
• EN 61000-6-3: 2011 (Emission)
• FCC 47 CFR Part 15 B (Emission)
Magnetic fields EN 61 000-4-8, Test level 5 for continuous field
(severe industrial environment)
Encapsulation
IP 67 (IEC 60529)
Shock 25 g (IEC 60068-2-27)
Vibration 2 g (IEC 60068-2-6)
Drop
2 m (6.6 ft.) on concrete floor (IEC 60068-2-31)
Safety (power supply) CE/EN/UL/CSA/PSE 60950-1
Physical data
Camera weight, incl. battery 1.1 ±0.05 kg (2.4 ±0.1 lb.)
Battery weight 0.152 kg (0.3 lb.)
Camera size (L × W × H) 120 × 125 × 280 mm (4.7 × 4.9 × 11 in.)
