FLIRTG165USERGUIDEDocumentIdentifier:TG165‐en‐US_AA
12
5.5DisplayIconandIndicatorDescriptions
Icon Description Icon Description

SettingsMenuicon

Grayscalepalettemenuselection

Calibrationdateicon

Hotironpalettemenuselection

Firmwarerevisionicon

Mattefinish(emissivitypreset0.95)

LASERpointersONicon

Semi‐mattefinish(emissivitypreset0.80)

SDmemorycarddetected

Semi‐glossfinish(emissivitypreset0.60)

SDcarddelete(erase)icon

Glossfinish(emissivitymenupreset0.30)

Imagecolorpaletteicon

CustomEmissivitymenuicon

Date/Timemenuicon

Temperatureunits

Hourglassicon

Previous/NextPageindicatorarrows

TargetingCrosshairs

Accept/Saveindicator

AutoPowerOff(APO)icon

Abort/Deleteindicator

Operationcomplete
Operationfailed

Emissivityicon
InformationMenushowsfirmware
revisionlevelandcalibrationdate
Batteryfullpower: Batteryempty: ACchargingicon*: USBPortchargingicon*: 
*BatterychargingiconsshownrepresentchargingwithmeterpowerOFF.Whenchargingwithmeter
powerON,thebatterystatusicon(top,rightofdisplay)animatesinasweepingmotion. 
