[3 — Controls and connections]
ThermaCAM™ PM575/595 Operator’s Manual
6
3 Controls and connections
3.1 Direct access buttons
The camera is controlled by pressing the direct access buttons and/or using the
joystick control.
Figure 3.1 Direct access buttons
The ↵ (enter) button [1] brings up the menu system of the camera in the view-
finder. Make your selection in the menu by using the joystick control. You accept
the menu choice and quit the menu mode by pressing the
↵ button. The ↵ button
also means Accept or Confirm.
Press the A (auto) button [2] to get the best image in the viewfinder automatically.
When this button is pressed an automatic calibration is also performed.
Press the S (save) button [3] shortly to switch between a frozen image and a live
image. To store the image to the PC-card press the S button for more than 1 sec.
The C (clear) button [4] is used when you need to skip a menu selection without
making any changes and leave the menu mode. The C button also means Escape
or Don’t accept.
