[5.3.6 — Temperature scale]
© FLIR Systems AB – Publ. No. 557 369 – Ed. A
21
above these three lines. In Setup
→Image→Data field, data presentation can be
selected on four different levels, None, Normal, Reduced or Extended. The back-
ground can be set either to Solid or Transparent. See “Setup menu” on page 35,
for detailed information.
5.3.6 Temperature scale
The temperature scale is displayed on the right-hand side of the screen. The scale
shows how the colours are distributed over the various temperatures in the image
with high temperatures at the upper end and low temperatures at the lower end.
The small boxes above and below the scale display what colours are used for tem-
peratures outside the scale. See also “Saturation col.” on page 38.
5.3.7 Status area
The status area shows the current action.
Examples:
Checking disk Msg is displayed when a PC-card ATA disk is inserted.
Frozen Msg is displayed when the image is frozen.
Saving G0101-01 Msg is displayed during the time an image with the name G0101-01 is
written to the disk.
Adjusting Msg is displayed when the camera performs an auto adjustment.
G0101-01 The recalled image name and the speaker symbol are displayed if the image
contains a voice comment.
G0101-01 T The recalled image name and the T symbol are displayed if the image
contains a text comment.
Zooming in/out Msg is displayed when zooming.
Focus far/near Msg is displayed when changing focus.
5.3.8 Joystick control
When a measurement function is chosen and activated by highlighting that func-
tion in the Analysis menu, the camera shows what measurement function is con-
nected to the joystick. This information is displayed at the bottom of the screen:
Joystick: Spot pos C: Remove
Joystick: Iso temp C: Remove
Joystick: Area size C: Remove
Joystick: Profile pos C: Remove
To deactivate a measurement function, press C when one of the above messages
is displayed.
