ThermaCAM™ PM575/595 Operator’s Manual
48
7.2.5 Power supply (optional)
CE certified.
UL and CSA approved.
7.3 Lens data
* At close focus.
Input: 100–240 VAC, 1.3 A.
Frequency: 50/60 Hz.
Output: 13.5 VDC.
Weight: 0.7 kg (1.55 lbs)
Maximum output: 55 W
Size: 200 x 96 x 60 mm (7.87" 3.78" 2.36")
Cable length: 1.2 m (4 ft)
OBJECT
DISTANCE
0.3 0.5 2.0 3.0 5.0 10.0 30.0 100.0 (M)
7°
HOR FOV
IFOV
-
-
-
-
-
-
-
-
0.5
1.7
1.2
3.6
3.6
11.3
12.2
38.0
(M)
(mm)
12°
HOR FOV
IFOV
-
-
-
-
0.4*
1.3
0.6
2.0
1.1
3.5
2.1
6.6
6.3
20.0
21.0
66.0
(M)
(mm)
24°
HOR FOV
IFOV
-
-
0.2*
0.7
0.8
2.6
1.3
4.0
2.1
6.6
4.2
13.0
12.0
40.0
42.0
130.0
(M)
(mm)
45°
HOR FOV
IFOV
0.2*
0.8
0.4
1.3
1.7
5.3
2.5
7.8
4.2
13.0
8.3
26.0
25.0
78.0
83.0
260.0
(M)
(mm)
80°
HOR FOV
IFOV
0.6
1.8
0.9
2.9
3.4
10.8
5.1
16.0
8.5
26.5
16.9
52.3
50.4
158.0
169.0
524.0
(M)
(mm)
