[5.3 — Menu area]
ThermaCAM™ PM575/595 Operator’s Manual
18
5.3 Menu area
The menu area is reached by pressing the ↵ button which activates the menu sys-
tem. Moving the joystick left/right brings out the different pull-down menus. Select-
ing an item in a pull-down menu is made by moving the joystick up/down. The
selected item is highlighted. Some of the functions might be marked grey, indicat-
ing that they cannot be activated under the current conditions. For example, this is
the case for the Open or Save commands if there is no PC-card disk inserted.
Actions when
↵ is pressed:
• If the selected pull-down menu item has three dots at the end (e.g. Open...) a
menu dialog will show up on the screen.
• If not, the selected menu item (e.g. Save) will be executed and the menu area
will be removed.
Pressing the C button will remove the pull down menu area and restore the normal
function for the joystick, i.e. focus/zoom.
5.3.1 Control box
Some selections in the menu area result in showing a control box in the bottom
left-hand corner of the screen.
Figure 5.6 Control box.
The control box is a horizontal table with different selection possibilities. The upper
line contains the selection headings and the lower line the value/alternative for
each selection.
Joystick functions:
• Left/right: Change item.
• Up/down: Change value/alternative.
The selected item is marked white/dark grey. Pressing the
↵ button saves
changes and removes the control box. Pressing the C button will remove the con-
trol box, cancel the changes and put the camera in normal mode, i.e. focus/zoom
function for the joystick.
5.3.2 Dialog boxes
Some selections in the menu area result in showing a dialog box on the screen.
