Flo CoRe+ Max - Page 21

21
Image Reference
Number
Included Material Quantity
1
Wall-mounted cable management system columns and
cable clamp
1
2 Lower wall mount bracket 1
3 Upper wall mount bracket 1
4 Spacing shim 2
5 Self-adhesive rubber band 1
6
¼-20 x 2¾ screw, ¼-20 bolt and split lock washer (max.
torque: 80 LB-IN [9.0 N-M])
1 each
6.1.1.1. Additional Material or Tools Required
Wall attachment hardware: ¼’’ diameter screw, washers, and wall anchors, as required.
