28
6.2.1. Required Material
The table below describes the material included with the EV charger. Use the number in the table to refer to
the material in the image.
Image Reference Number
Included Material Quantity
1 Cable management system columns and cable clamp 1
2 Empty column 1
3 Column mount bracket 2
4 Round spacing shims 2
5 Rectangular spacing shims 2
6 Self-adhesive rubber band 1
7 ¼-20 screws (1’’) (max. torque: 90 LB-IN [10.0 N-M]) 6
